Height: 450mm-520mm, upper plate thickness is 14mm-25mm,
middle plate thickness is 8mm-12mm,
down plate thickness is 16mm-25mm;
Material is Q345 manganese steel .
Tire
12R22.5/11R22.5/13R22.5/11.00R20/12.00R20(specificationcan be Optional)
King Pin
JOST brand 2.0 or 3.5 inch bolts type or Welding type
Support legs
JOST/FUWA/YAHUA brand or China brand 28ton(two speed or single speed )
Rear ladder
Dismountable or foldaway
Wheelbase
8050/7650+1300mm, 5060/6660/6960/6580+1310+1310mm
Spring leaf
8/10/12/16 pieces
Manhole Cover
2/3/4/5/6 piece Carbon steel API manhole cover ,500mm European standards
Brake Chamber
6 double brake chamber
Electrical System
24V, 7core socket, lights according to European standards
Accessory
One tooling boxes ,Two spare tire carrier, Two fire extinguisher
Other tools
A waterproof toolbox. (equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 2 unit cranking bar and instruction manual)
Discharge mouth
diameter is 280mm
Receptacle
7ways (7wire harness)
The Above Information is Standard Spec.If you want get more specific Spec.Please send inquity to us.
